Hydraulic 4Tie-bar Trimming Press

Hydraulic 4Tie-bar Trimming Press

Trimming flashe

Interlocking with Extractor Robot make it more efficient operation possible .There are 3 models; 10ton,20ton,30ton.

Model TP-VER10T
Capacity 10ton
Between tie bar 550×350mm
Stroke 350mm
Die-height 500mm(Max.)
Price JPY-,---,---(10ton)
Safety device Double push buttons Photocell curtain(Front)、Safety Cover(R,L, Rear)
Option Oil Cooler、Stroke counter
Spec./Model TP-VER10T TP-VER20T TP-VER30T
Capacity Ton 10 20 30
Bolster X*Y(mm) 700*500 800*600 1000*800
Between Tie-bar X*L(mm) 550*350 650*450 800*600
Tie-bar Diameter (mm) 50 60 70
Waist hole X*L(mm) 250*200 250*200 ---
Hydraulic Cylinder φ(mm) 100 130 160
Speed Control Downward speed high & low

10ton LMTP-10
10ton
LMTP-10

20ton
20ton

30ton
30ton
